GYRUS

Modular RF Amplifiers  for FM, Scientific & Pulse Applications
Sale to Commercial and Comunity Radio Stations Air cooled
Frequency Modulation 88 to 108 MHz Up to 80 kilowatt Stereo Analog & Digital

GYRUS Series FM Amplifiers Modules goes from 1kW to 2kW HIGH EFFICIENCY LDMOS FM AMPLIFIERS.This Equipment solution allows the possibility to be easily upgraded with useful options, in order to meet all the customer needs, due to the manufacture process it is an accessible system and it opens to huge modular options.
The GYRUS’s integrated CPU card allows a large number of monitoring parameter. An user-friendly menu visualized in a clear LCD display allows the configuration and setting of all the working parameters and the monitoring of the operating values.
With only 2 standard units, this amplifier can be used either as stand-alone amplifier or as basic component in higher power systems. GYRUS solid state amplifier mount high-power 1,2kW LDMOS pallets that guarantees superior power redundancy and high reliability in all operating conditions. Thanks to the use of the last generation LDMOS devices, the efficiency is more than 82%, even work not at the nominal power and produce a very low harmonic distortion and intermodulation products, this feature allows to handle digital signals and makes GYRUS Series intrinsically “digital ready”.
The final RF modules are completely broadband and self-protected against up to 65:1 mismatch level., moreover the high efficiency minimizes the heat dissipation and simplify the air cooled system. The use of modern Power Supply modules, with PFC technology allows a power factor better than 0,98 with high efficiency and spectral cleanliness towards the main power. It fully complies to all international specifications.
The AC input power supply is “Full range”, that allows constant performances even with AC input fluctuations. ROCK Series are equipped with protections against overvoltage, over-temperature and VSWR. TCP/IP SNMP telemetry and remote control are mount as an option.

Contact us or get a quotation

Please specific area code e.g. +39 0213213

Luxury FM Radio Transmitters Made in Italy for professional use. Up to 80kW of soft, clean and crystal sound for your Radio Station TEKO Broadcast Distributor of main brands of Broadcast Equipment
See on the follows links related products surely of your interest:

Professional world-class Performance FM Broadcast Transmitters
Complete guide about selection of FM Broadcast Equipment and FM
Drive in movie theater fm transmitter: complete turnkey package
AXON Series Low Power FM Transmitters and Exciter 30W to 1200W
CORTEX Series High Power Modular FM Transmitters 2kW to 80kW
AXON 300 High Performance Stereo 300 watt FM Transmitter
AXON 1000 High Performance Stereo 1000W FM Transmitter
CORTEX 5/3 High Power Modular FM Transmitter
CORTEX 6/3 High Power Modular 6kW FM Transmitter
CORTEX 10/5 High Power Modular 10kW FM Transmitter

UNIQUE SOLUTIONS: TOP PERFORMANCES AND RELIABILITY

  • HOT PLUG-IN POWER SUPPLY for Instant replacement of the power supplies, easy maintenance, without off-air. The power supply plug-in modules can be safely removed from the front panel without interrupting the transmission.
  • STANDARD MARKET AVAILABLE POWER SUPPLY
  • SMP: Superior Modular Philosophy
  • MODULARITY with very light amplifier modules (less than 17kg/34lbs each)
  • Maximum Redundancy
  • Ultra compact size 2U for each amplifier module
  • DIRECT INTERNET CONNECTION: all the WIRED Line components have direct connection to internet without the help of any external box or accessories.
  • LOWEST LOST OF POWER OF THE MARKET IN CASE OF FAILURE OF ONE MODULE: Due to combination of 2kW amplifier modules, extremely low output power loss in case of failure.
  • TOTALLY MADE IN ALLUINUM: for minimum weight and robustness.
  • AIR PROTECTION: all the internal components are designed to avoid the direct contact with the air, mainly the air coming in from the fans, this avoid all the failures produced by the air corrosion.
  • MIRROR Network Mirror System:
  • DIREC ACCESS TO MAIN COMMANDS
  • OVERALL STATUS SHOWING BY LED
  • TOUCH SCREEN BRAIN CONTROL UNIT: The control unit have the specific function to supervise the transmitter, even in case of failure of it (or turned off) manual control of the transmitter guarantee perfect operation.
  • Web control
  • Extremely detailed web control with all main parameters fully controllable and adjustable, available.
  • Weekly scheduler output power for energy consumption optimization management.
  • E-mails configuration available sent for any event.
  • Remotely upgradable
  • SMART BROWSING
  • 65:1 VSWR TOLERANCE
